Steel
Vertical Pitch Security Panel
Explore the key specifications of Vertical Pitch Security Panel for accurate, project-ready material selection.
- Tensile Strength: 450-650 N/mm2
- Mesh Size: Wire Thicknes · Panel Height · Panel Width
Overview
Other commonly used fence system that provide high level of security. Frequent mesh sizes and high resistance against external impacts make these panels more durable than the others.
Specifications
| Vertical Pitch Security Panel | |||||
|---|---|---|---|---|---|
| Mesh Size | Wire Thicknes | Panel Height | Panel Width | Number of Folds | Standards |
| 12,7 x 76,2 mm | Ø 4,00mm Ø 6,00mm Ø 8,00mm |
990 mm | 2,50 m (standard) 3,00 m available | 2 | Panel Norm TSE-EN-10223-7 Wire Norm TSE-EN-10218-2 Galvanization Norm EN10244-2 Class D (50 gr Zn/m2) |
| 1450 mm | 2 | ||||
| 1760 mm | 2 | ||||
| 1980 mm | 3 | ||||
| 2520 mm | 4 | ||||
| 2980 mm | 6 | ||||
| Colour | Available at any RAL colour (RAL6005 Standard) | ||||
| Finish | Galvanized steel wire to ensure high adhesion. On final layer either thermoplastic coating or electrostatic polyester powder coating | ||||
| Tensile Strength | 450-650 N/mm2 | ||||
| Profile Posts | Most common sizes are 40x60 mm, 50x50 mm and 60x60 mm | ||||
