Roofing and Facade
PUR PIR Insulated Wall Panel
Explore the key specifications of PUR PIR Insulated Wall Panel for accurate, project-ready material selection.
- Insulation Thickness: 40-50-60-70-75-80-100-120-150-180-200 mm
- Insulation Density: PUR: 38-42 kg/m3 & PIR: 42-45 kg/m3
Overview
Sandwich wall panels offer both aesthetic and smart solutions for your buildings thanks to its energy efficiency, fire resistance, elegant look and easy installation.
Polyisocyanurate (PIR) insulated panels have higher fire resistance performance than polyurethane (PUR) insulated panels.
Specifications
| PUR/PIR Insulated Wall Panel | |
|---|---|
| Product Group | Wall Panels |
| Product Details | Metal Sheet + PUR or PIR Insulant + Metal Sheet |
| Insulation Thickness | 40-50-60-70-75-80-100-120-150-180-200 mm |
| Insulation Density | PUR: 38-42 kg/m3 & PIR: 42-45 kg/m3 |
| Panel Width | 100-150-200-250-300 cm |
| Panel Length | 2 - 15 meters |
| Outer Sheet Thickness | 0,4 - 0,8 mm |
| Inner Sheet Thickness | 0,35 - 0,8 mm |
| Line Option | Standard, shallow fluted, deep fluted, sinusoidal wawe design |
| Screw Option | External or hidden |
| Colour Options | RAL (9002, 9006, 7042, 7016, 5010, 5015, 6018, 6029, 3009, 3011, 2004, 1028) |
| Thermal Conductivity | Depending on panel thickness, λ between 0,57 - 0,11 w/m2k (Acc. EN 14509) |
| Fire Performance | B-S2;D0 for PUR insulated, B-S1;D0 for PIR insulated panels (Acc. EN 13501-1) |
